- Pins & Bushings Turned?
- No
- Guiding Guard - Left
- Good
- Guiding Guard - Right
- Good
- Track Frame - Left
- Good
- Track Frame - Right
- Good
- Carrier Rollers Front
- Left: 29 mm Measurement, Left: 59% Worn, Right: 23 mm Measurement, Right: 36% Worn
- Idlers Front
- Left: 24 mm Measurement, Left: 32% Worn, Right: 26 mm Measurement, Right: 48% Worn
- Idlers Rear
- Left: 22 mm Measurement, Left: 59% Worn, Right: 23 mm Measurement, Right: 36% Worn
- Links
- Left: 144 mm Measurement, Left: 46% Worn, Right: 143 mm Measurement, Right: 53% Worn
- Pins & Bushings (External)
- Left: 10 mm Measurement, Left: 62% Worn, Right: 10 mm Measurement, Right: 62% Worn
- Segments
- Left: 205 mm Measurement, Left: 143% Worn, Right: 205 mm Measurement, Right: 143% Worn
- Track Roller 1
- Left: 25 mm Measurement, Left: 27% Worn, Right: 24 mm Measurement, Right: 32% Worn
- Track Roller 2
- Left: 21 mm Measurement, Left: 19% Worn, Right: 22 mm Measurement, Right: 24% Worn
- Track Roller 3
- Left: 20 mm Measurement, Left: 14% Worn, Right: 21 mm Measurement, Right: 19% Worn
- Track Roller 4
- Left: 20 mm Measurement, Left: 14% Worn, Right: 21 mm Measurement, Right: 19% Worn
- Track Roller 5
- Left: 21 mm Measurement, Left: 19% Worn, Right: 21 mm Measurement, Right: 19% Worn
- Track Roller 6
- Left: 22 mm Measurement, Left: 24% Worn, Right: 21 mm Measurement, Right: 19% Worn
- Track Roller 7
- Left: 20 mm Measurement, Left: 14% Worn, Right: 21 mm Measurement, Right: 19% Worn
- Track Roller 8
- Left: 22 mm Measurement, Left: 24% Worn, Right: 22 mm Measurement, Right: 24% Worn
- Track Shoe Grouser Height
- Left: 58 mm Measurement, Left: 61% Worn, Right: 58 Measurement, Right: 61% Worn
